PVC special Injection Moulding Machine
Minimum order quantity:1
Model NO.: AX/UPVC358 (358T)
| DESCROPTION | UNIT | MODEL: AX/UPVC-358 |
| A | B |
| INJECTION UNIT |
| Screw Diameter | mm | 60 | 65 |
| Screw L:D ratio | L/D | 22.8 | 21 |
| Shot Size (TheoreticalAX) | cm3 | 905 | 1060 |
| Injection Weight (PS) | g | 823 | 964 |
| Injection Rate | g/s | 250 | 296 |
| Injection Pressure | MPa | 206 | 176 |
| Max. Screw Speed | rpm | 0-165 |
| CLAMPING UNIT |
| Clamp Tonnage | kn | 3580 |
| Tonnage Stroke | mm | 650 |
| Space Between Tie Bars (W*H) | mm | 680X680 |
| Max. Mold Height | mm | 720 |
| Min. Mold Height | mm | 250 |
| Ejector Stroke | mm | 160 |
| Ejector Tonnage | kn | 90 |
| OTHERS |
| Max. pump Pressure | MPa | 16 |
| Pump Motor Power | kw | 37 |
| Heater Power | kw | 18.6 |
| Machine Dimension (LxWxH) | m*m*m | 6.9X1.91X2.28 |
| Machine Weight | Ton | 11.6 |
| Oil Tank Capacity | L | 650 |
