Techmation Servo Drive
ID688xxxx
Product feature：
1. Realize linkage, quick switching with follow, and coexistence of multiple control modes;
2. Using NET/CAN and other communication methods to establish digital communication with the upper computer, the control is more accurate and the operation is more convenient.
3, with short circuit, over current, over voltage, under voltage and other protection functions.
4. Communicate with servo through NET, change driver parameters through HMI interface, or debug or repair through mobile phone APP software.
1. Realize linkage, quick switching with follow, and coexistence of multiple control modes;
2. Using NET/CAN and other communication methods to establish digital communication with the upper computer, the control is more accurate and the operation is more convenient.
3, with short circuit, over current, over voltage, under voltage and other protection functions.
4. Communicate with servo through NET, change driver parameters through HMI interface, or debug or repair through mobile phone APP software.
Quantity:
| Product specifications | |||
| Product Model | Input Voltage/V | Output Power/kw | Rated Current/A |
| 1BX_DE688K1F3 | Three-phase 390~480 （±10%） | 11 | 25 |
| 1BX_DE688K5F3 | 15 | 32 | |
| 1BX_DE688K8F3 | 18.5 | 37 | |
| 1BX_DE688J2F3 | 22 | 45 | |
| 1BX_DE688I0F3 | 30 | 60 | |
| 1BX_DE688I7F3 | 37 | 75 | |
| 1BX_DE688H5F3 | 45 | 91 | |
| 1BX_DE688G5F3 | 55 | 112 | |
| 1BX_DE688E5F3 | 75 | 150 | |
| 1BX_DE688C0F3 | 90 | 176 | |
| |||
|---|---|---|---|
| Functional description | Specification indexes | ||
| Power input | Input voltage（V） | Three-phase 380 v; The voltage keeps fluctuating by plus ±10% | |
| Incoming current（A） | Please refer to the rating | ||
| Incoming frequency（Hz） | 50Hz or 60Hz， allowable frequency range ±5% | ||
| Power output | Output voltage（V） | 0~380V | |
| Output voltage（A） | Please refer to the table above | ||
| Outcoming frequency（KW） | Please refer to the table above | ||
| Control performance | Maximum output frequency | ||
| Vector control | ||
|
| ||
|
| ||
| Pressure instruction type | Analog instruction (DC0~10V) | ||
| FDEM | Analog instruction (DC0~10V) | ||
| Peripheral interface | Analog input | 3 ways，DC0~10V | |
| Analog output | 2 ways，DC0~10V | ||
| Digital switching quantity input | 6 ways | ||
| Relay output | 6 ways | ||
| Defensive function | Short circuit protection, over current protection, over voltage protection, under voltage protection, over temperature protection, overload protection | ||
| Communicating function | CAN communication,E_NET | ||
| Others |
| Wall mounting and flange mounting are supported | |
| Operating ambient temperature | -10~50℃， derating during 40℃~50℃ | ||
| Level of protection | IP20 | ||
| Forced cooling | ||
| Indoor, without direct sunlight, no dust, corrosive gas, flammable gas, oil mist, water vapor, dripping water or salt, etc | ||
| Lower than 1000 meters and lower than 1000 meters, the amount of reduction shall be 1% for each increase of 100 meters | ||
| Temperature | 5%~95%RH, no condensation | ||
| Vibration | ＜4.9m/s2（0.5G） | ||
| Storage temperature | -40℃~+70℃ | ||
