PORCHESON MC800AM controller
PORCHESON MC800AM controller
PORCHESON MC800AM controller
PORCHESON MC800AM controller

PORCHESON MC800AM controller

Model NO.: MC800AM

Features:

·Adopt ARM processor, low failure rate of system problem

·High integration, multi-function, high cost performance

·Simple operation and easy maintenance

·Multi-layer protection, safe and reliable,

·Quick response to customer on-site needs

·Support customer's secondary development and protect customer's core technology



ProjectSpecifications
Brand  Porcheson
Host model  MC800AM
Programming software

  PsMagic V3.28 (support user’s secondary development,

  language:ladder diagram +C language)

Performance  CPU: ARM;32nd CPU; program scanning cycle: 1.0ms
Analog input

  Position transducer: 0~2.5V, 6 channels single transducer/3

  channels  dualtransducer, precision: 12bit, Sampling period: 100KSPS

  Pressure detection:4 channels  0~10V
Temperature control

  8segments, self-learning PID control, display precision: 0.1℃,

  sensor type: K(default),J.

Voltage output  4 channels 16bit 0→10v with the fastest rising speed being 300ms
Current input  4 channels closed loop(0-1A),2 channels PWM(0-1A)
Input I

  39 channels wet contact (NPN),3 channels differential scrambler,Short

  circuit protection

Output O

  40 channela high power transistor with direct fuel valve, drive capability

  4.5A (full load test)

  11channels Wet Contact (relay) output:motor, lubrication, etc.
Communication interface  RS232、RS485、CAN
Working voltage  Service voltage: DC 24V
Environment

  Working temperature: -10℃~50℃; storage temperature: -25℃~55℃;

  relative humidity: 15%~85%

Recommended type  Middle and small vertical injection molding machines
Remarks

  Parameters of the product may be changed due to technical update

  or improvement without prior notice. All ordered products and

  parameters    are subject to the physical product.
