PORCHESON MC1000A controller

PORCHESON MC1000A controller

Model NO.: MC1000A

Features:

·ARM 800M high-speed processor high speed,high precision, High integration

·Stable and efficient system to meet requirements of various production environments

·Multilayer protection, safe and reliable

·Mixed power pioneer, hybrid servo closed loop control

·Quick response to customer site requirements

·User software redevelopment supported to protect clients' core technology


ProjectSpecifications
BrandPorcheson
Host modelMC1000A
Programming softwarePsMagic V3.28 (support user’s secondary development, language: ladder diagram +C language)
PerformanceCPU: A8 800M; FPGA: 132M; program scanning cycle: less than 100us
Analog inputPosition transducer: 0~4.1V, 8 channels single transducer/8 channels dual transducer, precision: 16bit, Sampling period: 250KSPS
Pressure detection: 0~10V, 4 channels, precision: 16bit,Sampling period: 350KSPS
Magnetic suspension  transducer 4 channels, precision: 0.02mm, Sampling period: about 1-10KSPS
Temperature control8 segments, self-learning PID control, display precision: 0.1℃, sensor type: K (default),J.
Voltage output4 channels 16bit 0→10v with the fastest rising speed being 300ms
Current output4 channels closed loop(0-1A),2 channels PWM(0-1A)
Input I32 channels wet contact (NPN),5 channels differential scrambler(3channels standard: AB,2 channels 500K differential scrambler)
Output O40 channela high power transistor with direct fuel valve, drive capability 4.5A (full load test), 2 channels 500K high-speed pulse output
11channels other 24V low power output:motor, lubrication, etc.
Communication interfaceRS422、RS485、CAN
Working voltageService voltage: DC 24V
EnvironmentWorking temperature: -10℃~50℃; storage temperature: -25℃~55℃; relative humidity: 15%~85%
Recommended typeMiddle, small high-speed ejection injection molding machines, mixed power injection molding machines
noteParameters of the product may be changed due to technical update or improvement without prior notice. All ordered products and parameters are subject to the physical product.
