Items	Unit	PET1200/298 S6
Injection Unit
Screw diameter	mm	67
Screw L/D ratio	L/D	24
Injection rate	g/s	447
Shot volume	㎤	1006
Shot weight	g	1207
	oz	42.6
Clamping Unit
Clamping force	kn	2980
Mold open stroke	mm	590
Distance between tie bars	mm	615X615
Movable platen size	mm	920X920
Mxaimum mould thickness	mm	630
Minimum mould thickness	mm	200
Ejection stroke	mm	170
Ejection force	kn	123
Number of ejector pins		12+1
Others
Pump Motor Power	kw	28.7
Heating capacality	mpa	16
Tank volume	L	540
Motor power	kw	23.6
Machine dimensiongs	m	6.85X1.56X2.0
Machine weight	t	9.5
