DESCROPTION	UNIT	MODEL: AX/UPVC-408
		A	B
INJECTION UNIT
Screw Diameter	mm	70	75
Screw L:D ratio	L/D	22.5	21
Shot Size (TheoreticalAX)	cm3	1366	1567
Injection Weight (PS)	g	1243	1426
Injection Rate	g/s	313	360
Injection Pressure	MPa	199	173
Max. Screw Speed	rpm	0-160
CLAMPING UNIT
Clamp Tonnage	kn	4080
Tonnage Stroke	mm	720
Space Between Tie Bars (W*H)	mm	730X730
Max. Mold Height	mm	750
Min. Mold Height	mm	250
Ejector Stroke	mm	180
Ejector Tonnage	kn	90
OTHERS
Max. pump Pressure	MPa	16
Pump Motor Power	kw	44
Heater Power	kw	26
Machine Dimension (LxWxH)	m*m*m	7.6X2.0X2.45
Machine Weight	Ton	15.5
Oil Tank Capacity	L	685
