Model NO.
MIDAS-M360(360T)
Quantity:
ItemsUnitM360/1820
Injection Unit
Screw diametermm606570
Screw L/D ratioL/D222220
Shot volume91910781251
Shot weightg8369811138
Injection pressure㎏/198169145
Injection rate/sec321377438
Plasticizing abilityKg/hr6983100
Max. screw speedrpm250
Clamping Unit
Clamping forceton360
Mold open strokemm650
Minimum mould thicknessmm270
Mxaimum mould thicknessmm685
Diameter of location ringmm125
Ejection forcekn80
Distance between tie barsmm670x620
Ejection strokemm180
Number of ejector rodspcs13
Others
Pump pressurempa16
Heating capacalitykw20
Motor powerkw37(125*2500
Tank volumel500
Machine dimensiongsm6.5X1.6X2.3
Machine weightt10
